Specifications
Specifications come from the current datasheet. Confirm against the datasheet below before committing a design.
Packs this works with
- PB3037HD29 7.2 V, 2.8 Ah
- PH2054HD34 14.4 V, 6.8 Ah
- PH2054QE34 14.4 V, 6.8 Ah
- PH2059HD29 28.8 V, 2.9 Ah
- PH2059HD34 28.8 V, 3.4 Ah
- PH2059QE34 28.8 V, 3.4 Ah
- PH3054HD29 14.4 V, 5.6 Ah
- PH3054QE29 14.4 V, 5.6 Ah
- PH3059HD29 28.8 V, 2.8 Ah
- PH3059QE29 28.8 V, 2.8 Ah
Documents
Datasheet on request. The current revision for this part
is issued by engineering. Ask for it and it comes with the quote.
About this part
P-Series Mating connector kit. Backshell, D-sub plug connector with (2) 40A solder pin contacts and related hardware.
